Dornier Tritos PP 3D weaving machine

System concept

The thread material is provided through a creel. A highly flexible Jacquard machine is used for the shedding. The rapier head draws the filling material into the open shed without any additional guide elements. For thick fabrics, an integrated guide and horizontal product take-up is available. Many add-on modules from the standard product program are also available for our 3D weaving machine.

DORNIER Composite Systems^® machines are designed for specific applications, so the machinery equipment can sometimes vary widely. But all DORNIER machines and systems have two features in common: exceptional quality and reliability.

Your added value

• High degree of flexibility regarding weave patterns and thread material
• Rigid mono-rapier for low filamentation
• High reproducibility
• Complex thread architectures and lattice-like preforms
• Reinforcing threads in X-, Y- and Z-directions
• High-performance multilayer fabrics
• Horizontal product take-off for high product quality
